The Weltool T16A is a compact tactical torch delivering a maximum throw of 598 metres and a peak beam intensity of 89000 candela. It houses a high-power X-LED primary light source and features Weltool's modular light head, body and tail cap design. Powering the torch is a Weltool UB18-12P 18350 lithium-ion battery, which is Micro-USB rechargeable via a port on the battery itself, offering a maximum runtime of 45 minutes. Constructed from aluminium alloy, it has an IP67 ingress protection rating and 1-metre impact resistance. The torch is operated by a tail switch rated for 50000 actuations, and includes reverse-polarity protection, over-discharge protection, and a high-efficiency constant current driver for flicker-free, noise-free operation.
Features
- Modular Design: The light head, body and tail cap are compatible with other components in Weltool's torch range.
- Reverse-Polarity and Over-Discharge Protection: Guards the battery and driver against incorrect insertion and deep discharge.
- Waterproof and Dustproof: IP67-rated for dust and water resistance, with 1-metre impact resistance.
- Accessory Compatible: Accepts the optional FR20 tactical finger ring and LF33 diffuser filter.
Package Includes
- 1 x Weltool T16A
- 1 x Weltool UB18-12P 1200mAh High-drain Micro-USB Rechargeable 18350 Li-ion Battery
- 1 x USB Charging Cable (USB-A to Micro-USB)
- 1 x Spare O-ring
Key Information
| Feature |
Details |
| Primary Light Source |
1 x High-power X-LED |
| Power Source |
1 x Weltool UB18-12P 1200mAh High-drain Micro-USB Rechargeable 18350 Li-ion Battery |
| Recharging Method |
Micro-USB (Charging Port on Battery) |
| Material |
Aluminium alloy |
| Warranty (Torch) |
5 years |
| Warranty (Battery) |
1 year |
| Warranty (Accessories) |
1 year |
ANSI/PLATO FL1 Specifications
| Feature |
Measurement |
| Maximum Light Output |
686 lumens |
| Maximum Runtime |
0.75 hours |
| Maximum Beam Distance |
598 metres |
| Peak Beam Intensity |
89000 candela |
| Impact Resistance |
1 metre |
| Ingress Protection Rating |
IP67 |
Dimensions
| Feature |
Measurement |
| Length |
114 mm |
| Head Diameter |
32.5 mm |
| Weight |
113 g |
